Background
SwiftUI’s evolution continues to simplify app development, and with SwiftUI 4.0, the new Table view brings an intuitive way to display tabular data.
Whether you’re building a productivity tool, managing records, or presenting structured lists, the Table API offers powerful capabilities with minimal code.
In this post, we’ll explore how to build dynamic tables using SwiftUI’s Table view, covering key features like multi-row selection, sorting, filtering, and expanding rows with the DisclosureTableRow.
By the end, you’ll be well-equipped to harness these new table features in your own SwiftUI apps.
Here is the GitHub Repo with full implementations and a demonstration of all functionality.
Introduction to Table in SwiftUI
Before SwiftUI 4.0, developers had to rely on List views or custom solutions to display tabular data. The introduction of Table in macOS, iOS, and iPadOS provides a more intuitive and powerful way to handle data in a grid-like structure.
A SwiftUI Table allows you to:
- Display multiple rows and columns of data.
- Easily define column headers and content for each row.
- Enable multi-row selection.
- Apply sorting, filtering, and expandable rows for richer user experiences.
Setting up the Data Models for the Table
We’ll start by creating a Student model, along with associated data for each student’s grade history. Our model will include a student’s name, ID, and grades for subjects like maths, science, and more.
// MARK: - Student Model
struct Student: Codable, Identifiable {
let id: String
let name: String
let gradeHistory: GradeHistory
var students: [Student] = []
enum CodingKeys: String, CodingKey {
case id, name
case gradeHistory = "grade_history"
case students
}
}
// MARK: - GradeHistory Model
struct GradeHistory: Codable, Identifiable{
let id: String?
let semester: String
let subjects: Subjects
init(
id: String? = UUID().uuidString,
semester: String,
subjects: Subjects
) {
self.id = id ?? UUID().uuidString
self.semester = semester
self.subjects = subjects
}
}
// MARK: - Subjects Model
struct Subjects: Codable, Identifiable {
let id: String?
let math: Int
let science: Int
let english: Int
let physics: Int
let computer: Int
let socialScience: Int
init(
id: String? = nil,
math: Int,
science: Int,
english: Int,
physics: Int,
computer: Int,
socialScience: Int
) {
self.id = id ?? UUID().uuidString
self.math = math
self.science = science
self.english = english
self.physics = physics
self.computer = computer
self.socialScience = socialScience
}
enum CodingKeys: String, CodingKey {
case id = "id"
case math = "Math"
case science = "Science"
case english = "English"
case physics = "Physics"
case computer = "Computer"
case socialScience = "Social Science"
}
}
To populate our table, we’ll create a list of sample student data, To do that I have added a JSON file that contains a long list of Student data. and reading local files with one helper class that reads data from it and returns a decoded [Student] struct.
Here is the StudentRepository that uses that helper and gets our model.
class StudentRepository {
init() {
}
func getStudents() async -> Result<Students, Error> {
var students: Students = Students(students: [])
do {
students = try await JSONHelper
.readJSONFromFile(fileName: JSONHelper.templateName,
type: Students.self)
return Result.success(students)
} catch {
return Result.failure(error)
}
}
}
Now we will use this repository everywhere where we need students.
Creating a Basic Table
Now let’s create a simple table that displays the student’s name, ID, and their grades for each subject.
struct PlainTableView: View {
@State var viewModel: PlainTableViewModel
var body: some View {
Group {
Table(viewModel.students) {
TableColumn("Index") { student in
let index = (viewModel.students.firstIndex(
where: { $0.id == student
.id }) ?? 0)
Text("No. \(index + 1)")
}
TableColumn("Id", value: \.id)
TableColumn("Name", value: \.name)
.width(min: 150)
TableColumn("Math") { student in
Text("\(student.gradeHistory.subjects.math)")
.foregroundStyle(gradeColor(for: student.gradeHistory.subjects.math))
}
TableColumn("Science") { student in
Text("\(student.gradeHistory.subjects.science)")
.foregroundStyle(gradeColor(for: student.gradeHistory.subjects.science))
}
TableColumn("English") { student in
Text("\(student.gradeHistory.subjects.english)")
.foregroundStyle(gradeColor(for: student.gradeHistory.subjects.english))
}
TableColumn("Physics") { student in
Text("\(student.gradeHistory.subjects.physics)")
.foregroundStyle(gradeColor(for: student.gradeHistory.subjects.physics))
}
TableColumn("Computer") { student in
Text("\(student.gradeHistory.subjects.computer)")
.foregroundStyle(gradeColor(for: student.gradeHistory.subjects.computer))
}
TableColumn("Social Science") { student in
Text("\(student.gradeHistory.subjects.socialScience)")
.foregroundStyle(gradeColor(for: student.gradeHistory.subjects.socialScience))
}
}
.tint(Color.purple.opacity(0.7))
.navigationTitle("Plain Table")
.task {
await viewModel.fetchStudents()
}
}
}
// Helper function to set color based on grade
private func gradeColor(for grade: Int) -> Color {
switch grade {
case 90...100:
return .green
case 75..<90:
return .yellow
default:
return .red
}
}
}
Key Points:
- The Table view takes an array of students and defines columns using
TableColumn. - Each column displays relevant data, like the student’s name, ID, and grades according to subjects.
Adding Multiple/Single Selection Support
SwiftUI allows multi-row selection in tables, which is useful when users want to select multiple students for bulk actions.
Step 1: Add a Set To track Selected Rows
We’ll track selected rows using a Set of the student’s ID: and to do that we’ll add that Set to our viewModel like following.
var selectedStudents: Set<Student.ID> = []
To make it a single selection, we will use options Student.ID? instead Set of ID
var selectedStudents: Student.ID? = nil
Step 2: Bind the Table’s Selection
We bind the table’s selection to the selectedStudents set. And need to add EditButton to enable edit mode for multiple selections like the following.
Table(students, selection: $selectedStudents) {
// TableColumns...
}
#if os(iOS)
.toolbar(content: {
EditButton()
})
#endif
With this setup, users can select multiple rows, and their IDs are stored in the selectedStudents set.
Sorting Students by Name, ID and Subject Grade
Sorting allows users to view data in a preferred order. Let’s add sorting by student name and ID and subjects grade-wise.
Step 1: Define Sorting Rule
Here we are going to sort Sutdents by name ID and subject grade so that we can define KeyPathComparator which sorts data with the provided path’s value like the following in our view.
var sortOrder = [
KeyPathComparator(\Student.name),
KeyPathComparator(\Student.gradeHistory.subjects.math)
]
Step 2: Update TableColumns
We need to update table columns arguments to provide the right path to sort with like the following.
Table(viewModel.students,
sortOrder: $viewModel.sortOrder) {
TableColumn("Index") { student in
let index = (viewModel.students.firstIndex(
where: { $0.id == student
.id }) ?? 0)
Text("No. \(index + 1)")
}
TableColumn("Id", value: \.id)
TableColumn("Name", value: \.name)
.width(min: 150)
TableColumn("Math", value:\.gradeHistory.subjects.math) {
Text("\($0.gradeHistory.subjects.math)")
.foregroundStyle(gradeColor(for: $0.gradeHistory.subjects.math))
}
TableColumn("Science", value: \.gradeHistory.subjects.science) {
Text("\($0.gradeHistory.subjects.science)")
.foregroundStyle(gradeColor(for: $0.gradeHistory.subjects.science))
}
TableColumn("English", value: \.gradeHistory.subjects.english) {
Text("\($0.gradeHistory.subjects.english)")
.foregroundStyle(gradeColor(for: $0.gradeHistory.subjects.english))
}
TableColumn("Physics", value: \.gradeHistory.subjects.physics) {
Text("\($0.gradeHistory.subjects.physics)")
.foregroundStyle(gradeColor(for: $0.gradeHistory.subjects.physics))
}
TableColumn("Computer", value: \.gradeHistory.subjects.computer) {
Text("\($0.gradeHistory.subjects.computer)")
.foregroundStyle(gradeColor(for: $0.gradeHistory.subjects.computer))
}
TableColumn("Social Science", value: \.gradeHistory.subjects.socialScience) {
Text("\($0.gradeHistory.subjects.socialScience)")
.foregroundStyle(gradeColor(for: $0.gradeHistory.subjects.socialScience))
}
}
.onChange(of: viewModel.sortOrder) {
viewModel.students.sort(using: viewModel.sortOrder)
}
Step 3: Add Sorting State Observer
To manage sorting we’ll observe sortOrder and on change of that sort our students
To do that, we’ll need to add the following code in our view.
.onChange(of: viewModel.sortOrder) {
viewModel.students.sort(using: viewModel.sortOrder)
}
It seems like magic, right? Let’s see how it works.
Filtering Students by Search Input
We can add filtering functionality to allow users to search for students by name, ID, or subject grades.
Step 1: Add a Search Text State
We add a Published variable in our viewModel to store the user’s search input:
We are adding just var not adding Published property wrapper as we are using the latest Observable property wrapper on our viewModel class. So all variables are default published.
var searchText: String = ""
Step 2: Filter Students Based on Search Text
We modify our students to only show students that match the search text:
var _students: [Student] = []
var students: [Student] {
var data: [Student] = _students
if !searchText.isEmpty {
data = _students.filter { student in
student.name.lowercased().contains(searchText.lowercased()) ||
student.id.lowercased().contains(searchText.lowercased()) ||
"\(student.gradeHistory.subjects.math)".contains(searchText) ||
"\(student.gradeHistory.subjects.science)".contains(searchText) ||
"\(student.gradeHistory.subjects.english)".contains(searchText) ||
"\(student.gradeHistory.subjects.physics)".contains(searchText) ||
"\(student.gradeHistory.subjects.computer)".contains(searchText) ||
"\(student.gradeHistory.subjects.socialScience)".contains(searchText)
}
}
return data
}
Step 3: Add a Searchable Modifier
we add the searchable modifier to the Table view:
Table(viewModel.students,
columns: {
///TableColumn...
})
.searchable(text: $viewModel.searchText, prompt: "Search by Name id & grades")
This adds a search bar to the table, allowing users to filter data in real-time.
Interesting!, isn’t it?
This post only has basic Table creation and selection relatad things, to read the complete guide including Table with sorting expandable row and context manu support implementation please visit this blog.
The post is originally published on canopas.com.
Here is the GitHub Repo with full implementations and a demonstration of all functionality.
