Adding charts using the Highcharts library to an Angular application

#angular #charts #highcharts #tutorial

Introduction

Angular is a development platform for building WEB, mobile and desktop applications using HTML, CSS and TypeScript (JavaScript). Currently, Angular is at version 15 and Google is the main maintainer of the project.

highcharts is a rich and interactive charts library based on SVG.

Prerequisites

Before you start, you need to install and configure the tools:

Getting started

Create the Angular application

1. Let's create the application with the Angular base structure using the @angular/cli with the route file and the SCSS style format.

ng new angular-highcharts
? Would you like to add Angular routing? Yes
? Which stylesheet format would you like to use? SCSS   [ https://sass-lang.com/documentation/syntax#scss                ]
CREATE angular-highcharts/README.md (1063 bytes)
CREATE angular-highcharts/.editorconfig (274 bytes)
CREATE angular-highcharts/.gitignore (604 bytes)
CREATE angular-highcharts/angular.json (3279 bytes)
CREATE angular-highcharts/package.json (1080 bytes)
CREATE angular-highcharts/tsconfig.json (783 bytes)
CREATE angular-highcharts/.browserslistrc (703 bytes)
CREATE angular-highcharts/karma.conf.js (1435 bytes)
CREATE angular-highcharts/tsconfig.app.json (287 bytes)
CREATE angular-highcharts/tsconfig.spec.json (333 bytes)
CREATE angular-highcharts/src/favicon.ico (948 bytes)
CREATE angular-highcharts/src/index.html (303 bytes)
CREATE angular-highcharts/src/main.ts (372 bytes)
CREATE angular-highcharts/src/polyfills.ts (2820 bytes)
CREATE angular-highcharts/src/styles.scss (80 bytes)
CREATE angular-highcharts/src/test.ts (788 bytes)
CREATE angular-highcharts/src/assets/.gitkeep (0 bytes)
CREATE angular-highcharts/src/environments/environment.prod.ts (51 bytes)
CREATE angular-highcharts/src/environments/environment.ts (658 bytes)
CREATE angular-highcharts/src/app/app-routing.module.ts (245 bytes)
CREATE angular-highcharts/src/app/app.module.ts (393 bytes)
CREATE angular-highcharts/src/app/app.component.scss (0 bytes)
CREATE angular-highcharts/src/app/app.component.html (24617 bytes)
CREATE angular-highcharts/src/app/app.component.spec.ts (1109 bytes)
CREATE angular-highcharts/src/app/app.component.ts (223 bytes)
✔ Packages installed successfully.
Enter fullscreen mode Exit fullscreen mode

2. Install and configure the Bootstrap CSS framework. Do steps 2 and 3 of the post Adding the Bootstrap CSS framework to an Angular application.

3. Install the highcharts library.

npm install highcharts
Enter fullscreen mode Exit fullscreen mode

4. Remove the contents of the AppComponent class from the src/app/app.component.ts file. Import the Highcharts, HighchartsMore and HighchartsSolidGauge services and create the createChartGauge, createChartPie, createChartColumn and createChartLine methods as below.

import { AfterViewInit, Component } from '@angular/core';
import * as Highcharts from 'highcharts';
import HighchartsMore from 'highcharts/highcharts-more';
import HighchartsSolidGauge from 'highcharts/modules/solid-gauge';

HighchartsMore(Highcharts);
HighchartsSolidGauge(Highcharts);

@Component({
  selector: 'app-root',
  templateUrl: './app.component.html',
  styleUrls: ['./app.component.scss'],
})
export class AppComponent implements AfterViewInit {

  public ngAfterViewInit(): void {
    this.createChartGauge();
    this.createChartPie();
    this.createChartColumn();
    this.createChartLine();
  }

  private getRandomNumber(min: number, max: number): number {
    return Math.floor(Math.random() * (max - min + 1) + min)
  }

  private createChartGauge(): void {
    const chart = Highcharts.chart('chart-gauge', {
      chart: {
        type: 'solidgauge',
      },
      title: {
        text: 'Gauge Chart',
      },
      credits: {
        enabled: false,
      },
      pane: {
        startAngle: -90,
        endAngle: 90,
        center: ['50%', '85%'],
        size: '160%',
        background: {
            innerRadius: '60%',
            outerRadius: '100%',
            shape: 'arc',
        },
      },
      yAxis: {
        min: 0,
        max: 100,
        stops: [
          [0.1, '#55BF3B'], // green
          [0.5, '#DDDF0D'], // yellow
          [0.9, '#DF5353'], // red
        ],
        minorTickInterval: null,
        tickAmount: 2,
        labels: {
          y: 16,
        },
      },
      plotOptions: {
        solidgauge: {
          dataLabels: {
            y: -25,
            borderWidth: 0,
            useHTML: true,
          },
        },
      },
      tooltip: {
        enabled: false,
      },
      series: [{
        name: null,
        data: [this.getRandomNumber(0, 100)],
        dataLabels: {
          format: '<div style="text-align: center"><span style="font-size: 1.25rem">{y}</span></div>',
        },
      }],
    } as any);

    setInterval(() => {
      chart.series[0].points[0].update(this.getRandomNumber(0, 100));
    }, 1000);
  }

  private createChartPie(): void {
    let date = new Date();
    const data: any[] = [];

    for (let i = 0; i < 5; i++) {
      date.setDate(new Date().getDate() + i);
      data.push({
        name: `${date.getDate()}/${date.getMonth() + 1}`,
        y: this.getRandomNumber(0, 1000),
      });
    }

    const chart = Highcharts.chart('chart-pie', {
      chart: {
        type: 'pie',
      },
      title: {
        text: 'Pie Chart',
      },
      credits: {
        enabled: false,
      },
      tooltip: {
        headerFormat: `<span class="mb-2">Date: {point.key}</span><br>`,
        pointFormat: '<span>Amount: {point.y}</span>',
        useHTML: true,
      },
      series: [{
        name: null,
        innerSize: '50%',
        data,
      }],
    } as any);

    setInterval(() => {
      date.setDate(date.getDate() + 1);
      chart.series[0].addPoint({
        name: `${date.getDate()}/${date.getMonth() + 1}`,
        y: this.getRandomNumber(0, 1000),
      }, true, true);
    }, 1500);
  }

  private createChartColumn(): void {
    let date = new Date();
    const data: any[] = [];

    for (let i = 0; i < 10; i++) {
      date.setDate(new Date().getDate() + i);
      data.push({
        name: `${date.getDate()}/${date.getMonth() + 1}`,
        y: this.getRandomNumber(0, 1000),
      });
    }

    const chart = Highcharts.chart('chart-column' as any, {
      chart: {
        type: 'column',
      },
      title: {
        text: 'Column Chart',
      },
      credits: {
        enabled: false,
      },
      legend: {
        enabled: false,
      },
      yAxis: {
        min: 0,
        title: undefined,
      },
      xAxis: {
        type: 'category',
      },
      tooltip: {
        headerFormat: `<div>Date: {point.key}</div>`,
        pointFormat: `<div>{series.name}: {point.y}</div>`,
        shared: true,
        useHTML: true,
      },
      plotOptions: {
        bar: {
          dataLabels: {
            enabled: true,
          },
        },
      },
      series: [{
        name: 'Amount',
        data,
      }],
    } as any);

    setInterval(() => {
      date.setDate(date.getDate() + 1);
      chart.series[0].addPoint({
        name: `${date.getDate()}/${date.getMonth() + 1}`,
        y: this.getRandomNumber(0, 1000),
      }, true, true);
    }, 1500);
  }

  private createChartLine(): void {
    let date = new Date();
    const data: any[] = [];

    for (let i = 0; i < 10; i++) {
      date.setDate(new Date().getDate() + i);
      data.push([`${date.getDate()}/${date.getMonth() + 1}`, this.getRandomNumber(0, 1000)]);
    }

    const chart = Highcharts.chart('chart-line', {
      chart: {
        type: 'line',
      },
      title: {
        text: 'Line Chart',
      },
      credits: {
        enabled: false,
      },
      legend: {
        enabled: false,
      },
      yAxis: {
        title: {
          text: null,
        }
      },
      xAxis: {
        type: 'category',
      },
      tooltip: {
        headerFormat: `<div>Date: {point.key}</div>`,
        pointFormat: `<div>{series.name}: {point.y}</div>`,
        shared: true,
        useHTML: true,
      },
      series: [{
        name: 'Amount',
        data,
      }],
    } as any);

    setInterval(() => {
      date.setDate(date.getDate() + 1);
      chart.series[0].addPoint([`${date.getDate()}/${date.getMonth() + 1}`, this.getRandomNumber(0, 1000)], true, true);
    }, 1500);
  }

}
Enter fullscreen mode Exit fullscreen mode

5. Remove the contents of the src/app/app.component.html file. Add the div tags for each chart as below.

<div class="container-fluid py-3">
  <h1>Angular Highcharts</h1>

  <div class="row mt-5">
    <div class="col-6">
      <div id="chart-gauge"></div>
    </div>
    <div class="col-6">
      <div id="chart-pie"></div>
    </div>
  </div>
  <div class="row mt-5">
    <div class="col-6">
      <div id="chart-column"></div>
    </div>
    <div class="col-6">
      <div id="chart-line"></div>
    </div>
  </div>
</div>
Enter fullscreen mode Exit fullscreen mode

6. Add the style in the src/app/app.component.scss file as below.

#chart-gauge, #chart-pie, #chart-column, #chart-line {
  display: block;
  min-width: 150px;
  max-width: 400px;
  height: 200px;
  margin: 0 auto;
}
Enter fullscreen mode Exit fullscreen mode

7. Run the application with the command below.

npm start

> angular-highcharts@1.0.0 start
> ng serve

✔ Browser application bundle generation complete.

Initial Chunk Files | Names         |      Size
vendor.js           | vendor        |   2.79 MB
styles.css          | styles        | 266.63 kB
polyfills.js        | polyfills     | 128.52 kB
scripts.js          | scripts       |  77.06 kB
main.js             | main          |  18.40 kB
runtime.js          | runtime       |   6.64 kB

                    | Initial Total |   3.28 MB

Build at: 2021-09-09T01:25:33.291Z - Hash: 2495029c373d88bd55c1 - Time: 27953ms

** Angular Live Development Server is listening on localhost:4200, open your browser on http://localhost:4200/ **


✔ Compiled successfully.
Enter fullscreen mode Exit fullscreen mode

8. Ready! Access the URL http://localhost:4200/ and check if the application is working. See the application working on GitHub Pages and Stackblitz.

Angular Highcharts

The application repository is available at https://github.com/rodrigokamada/angular-highcharts.

This tutorial was posted on my blog in portuguese.
