Cover image for HarmonyOS Flutter in action: 03 - integrated with Webview in development
shaohushuo
shaohushuo

Posted on

HarmonyOS Flutter in action: 03 - integrated with Webview in development

There are two main scenarios

Use third-party libraries

For example, using the 'flutter_inappwebview' plugin, configure in the pubspec.lock file:

flutter_inappwebview:
git:
url: https://gitcode.com/openharmony-sig/flutter_inappwebview.git
path: "flutter_inappwebview"
Enter fullscreen mode Exit fullscreen mode

Or use the webview_flutter plugin

webview_flutter:
git:
url: https://gitcode.com/openharmony-sig/flutter_packages.git
path: "packages/webview_flutter/webview_flutter"
Enter fullscreen mode Exit fullscreen mode

Write native ArkTS code to implement PlatformView

Create an entryablitiy

Configure ablitiy in src/main/module.json5

    "abilities": [
      {
        "name": "EntryAbility",
        "srcEntry": "./ets/entryability/EntryAbility.ets",
        "description": "$string:EntryAbility_desc",
        "icon": "$media:icon",
        "label": "$string:EntryAbility_label",
        "startWindowIcon": "$media:icon",
        "startWindowBackground": "$color:start_window_background",
        "exported": true,
        "skills": [
          {
            "entities": [
              "entity.system.home"
            ],
            "actions": [
              "action.system.home"
            ]
          }
        ],
        "orientation": "landscape"
      }
    ],
Enter fullscreen mode Exit fullscreen mode

cat src/main/entryablity/CustomFactory.ets

import { BinaryMessenger } from '@ohos/flutter_ohos/src/main/ets/plugin/common/BinaryMessenger';
import MessageCodec from '@ohos/flutter_ohos/src/main/ets/plugin/common/MessageCodec';
import PlatformViewFactory from '@ohos/flutter_ohos/src/main/ets/plugin/platform/PlatformViewFactory';
import { CustomView } from './CustomView';
import common from '@ohos.app.ability.common';
import PlatformView from '@ohos/flutter_ohos/src/main/ets/plugin/platform/PlatformView';

export class CustomFactory extends PlatformViewFactory {
  message: BinaryMessenger;

  constructor(message: BinaryMessenger, createArgsCodes: MessageCodec<Object>) {
    super(createArgsCodes);
    this.message = message;
  }

  public create(context: common.Context, viewId: number, args: Object): PlatformView {
    return new CustomView(context, viewId, args, this.message);
  }
}
Enter fullscreen mode Exit fullscreen mode

cat src/main/entryablity/CustomPlugin.ets

import  { FlutterPlugin,
  FlutterPluginBinding } from '@ohos/flutter_ohos/src/main/ets/embedding/engine/plugins/FlutterPlugin';
import StandardMessageCodec from '@ohos/flutter_ohos/src/main/ets/plugin/common/StandardMessageCodec';
import { CustomFactory } from './CustomFactory';

export class CustomPlugin implements FlutterPlugin {
  getUniqueClassName(): string {
    return 'CustomPlugin';
  }

  onAttachedToEngine(binding: FlutterPluginBinding): void {
    binding.getPlatformViewRegistry()?.
    registerViewFactory('com.rex.custom.ohos/customView', new CustomFactory(binding.getBinaryMessenger(), StandardMessageCodec.INSTANCE));
  }

  onDetachedFromEngine(binding: FlutterPluginBinding): void {}
}
Enter fullscreen mode Exit fullscreen mode

cat src/main/entryablity/CustomView.ets

import MethodChannel, {
  MethodCallHandler,
  MethodResult
} from '@ohos/flutter_ohos/src/main/ets/plugin/common/MethodChannel';
import PlatformView, { Params } from '@ohos/flutter_ohos/src/main/ets/plugin/platform/PlatformView';
import common from '@ohos.app.ability.common';
import { BinaryMessenger } from '@ohos/flutter_ohos/src/main/ets/plugin/common/BinaryMessenger';
import StandardMethodCodec from '@ohos/flutter_ohos/src/main/ets/plugin/common/StandardMethodCodec';
import MethodCall from '@ohos/flutter_ohos/src/main/ets/plugin/common/MethodCall';
import { webview } from '@kit.ArkWeb';

@Component
struct ButtonComponent {
  @Prop params: Params
  customView: CustomView = this.params.platformView as CustomView
  @StorageLink('numValue') storageLink: string = "first"
  @State bkColor: Color = Color.Red

  private webviewController: WebviewController = new webview.WebviewController()

  build() {
    Web({src: 'https://baidu.com', controller: this.webviewController})
      .domStorageAccess(true)
      .fileAccess(true)
      .mixedMode(MixedMode.All)
      .databaseAccess(true)
      .userAgent("Mozilla/5.0 (Windows NT 6.1; WOW64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/39.0.2171.71 Safari/537.36")
  }
}

@Builder
function ButtonBuilder(params: Params) {
  ButtonComponent({ params: params })
    .backgroundColor(Color.Transparent)
}

AppStorage.setOrCreate('numValue', 'test')

@Observed
export class CustomView extends PlatformView implements MethodCallHandler {
  numValue: string = "test";

  methodChannel: MethodChannel;
  index: number = 1;

  constructor(context: common.Context, viewId: number, args: ESObject, message: BinaryMessenger) {
    super();
    // Registration of the message channel.
    this.methodChannel = new MethodChannel(message, `com.rex.custom.ohos/customView${viewId}`, StandardMethodCodec.INSTANCE);
    this.methodChannel.setMethodCallHandler(this);
  }

  onMethodCall(call: MethodCall, result: MethodResult): void {
    // Accept a message from Dart's side
    let method: string = call.method;
    let link1: SubscribedAbstractProperty<number> = AppStorage.link('numValue');
    switch (method) {
      case 'getMessageFromFlutterView':
        let value: ESObject = call.args;
        this.numValue = value;
        link1.set(value)
        console.log("nodeController receive message from dart: " + this.numValue);
        result.success(true);
        break;
    }
  }

  public  sendMessage = () => {
    console.log("nodeController sendMessage")
    //Send a message to the Dart side
    this.methodChannel.invokeMethod('getMessageFromOhosView', 'natvie - ' + this.index++);
  }

  getView(): WrappedBuilder<[Params]> {
    return new WrappedBuilder(ButtonBuilder);
  }

  dispose(): void {
  }
}
Enter fullscreen mode Exit fullscreen mode

cat src/main/entryablity/EntryAbility.ets

import { FlutterAbility, FlutterEngine } from '@ohos/flutter_ohos';
import { GeneratedPluginRegistrant } from '../plugins/GeneratedPluginRegistrant';
import { CustomPlugin } from './CustomPlugin';

export default class EntryAbility extends FlutterAbility {
  configureFlutterEngine(flutterEngine: FlutterEngine) {
    super.configureFlutterEngine(flutterEngine)
    GeneratedPluginRegistrant.registerWith(flutterEngine)
    this.addPlugin(new CustomPlugin())
  }
}

Enter fullscreen mode Exit fullscreen mode

create pages

cat src/main/ets/pages/index.ets

import common from '@ohos.app.ability.common';
import { FlutterPage } from '@ohos/flutter_ohos'

let storage = LocalStorage.getShared()
const EVENT_BACK_PRESS = 'EVENT_BACK_PRESS'

@Entry(storage)
@Component
struct Index {
  private context = getContext(this) as common.UIAbilityContext
  @LocalStorageLink('viewId') viewId: string = "";

  build() {
    Column() {
      FlutterPage({ viewId: this.viewId })
    }
  }

  onBackPress(): boolean {
    this.context.eventHub.emit(EVENT_BACK_PRESS)
    return true
  }
}
Enter fullscreen mode Exit fullscreen mode

Configure routes in src/main/resources/base/profile/main_page.json

{
  "src": [
    "pages/Index"
  ]
}
Enter fullscreen mode Exit fullscreen mode

Call the PlatformView on the Dart side

Scaffold(
appBar: AppBar(title: Text('code')),
body: OhosView(
viewType: 'com.rex.custom.ohos/customView',
// onPlatformViewCreated: _onPlatformViewCreated,
creationParams: const <String, dynamic>{'initParams': 'hello world'},
creationParamsCodec: const StandardMessageCodec(),
)
Enter fullscreen mode Exit fullscreen mode

References
